Jayco Embark Motor Home Class A - Diesel

Previous
Next
1 of 11

Jayco would like to be the first to welcome you to a new line of luxury with this Embark Class A diesel motorhome. When you travel in one of these all-inclusive and extravagant vehicles, you will forget that you aren't in your own home. From the Spartan® K1 raised rail chassis, to the Allison® 3000 MH 6-Speed transmission, you will certainly experience the quality craftsmanship that is a part of the Jayco difference. This structure is built upon a solid foundation you can trust with X-bridge frames welded into the chassis frame and a steel-reinforced front cap and windshield frame.



In the Jayco Embark, you will find that style meets functionality. Each bedroom contains a king-size mattress and a 32" LED HDTV so that you can unwind and sleep peacefully after a long day of hiking in the woods. When you wake up in the morning, you will find residential appliances in the kitchen to make breakfast preparations just as easy as in your own home, and the entire coach is stocked with plenty of storage space, both on the interior and exterior, to make packing for your upcoming trip simpler than ever before.



This Jayco Embark Class A diesel motorhome is a new line of luxury that you won't want to wait to experience for yourself!

  • Embark 37MB

    Embark 37MB Floorplan Image

    Take a Virtual Tour

    Jayco Embark Class A diesel motorhome 37MB highlights: Outdoor Entertainment ... more about Embark 37MB

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 5
    Slides 4
    Length 37 ft 10 in
    Ext Width 8 ft 5 in
    Ext Height 12 ft 10 in
    Int Height 7 ft
    Exterior Color Desert Dusk, Night Flight, Summer Solstice
    Hitch Weight 10000 lbs
    Gross Weight 32000 lbs
    Dry Weight 27028 lbs
    Fresh Water Capacity 100 gals
    Grey Water Capacity 62 gals
    Black Water Capacity 41 gals
    Tire Size 22.5
    Furnace BTU 35000 btu
    Generator Onan 8000 Watt Diesel with Auto Start
    Fuel Type Diesel
    Engine Cummins ISB Turbocharged
    Chassis Spartan K1 Raised Rail
    Horsepower 360 hp
    Fuel Capacity 100 gals
    Wheelbase 236 in
    Available Beds King
    Torque 800 ft-lb
    Refrigerator Type Whirlpool Residential
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 30" x 36"
    Number of Awnings 1
    Axle Weight Front 12000 lbs
    Axle Weight Rear 20000 lbs
    LP Tank Capacity 16.5 lbs.
    Water Heater Capacity 10 gal.
    Water Heater Type Gas/Electric
    AC BTU 30000 btu
    Basement Storage 140 cu. ft.
    TV Info Coach 50" LED HDTV, BR 32" LED HDTV, Exterior 39" LED HDTV
    Awning Info 17' Electric with LED Lights
    Washer/Dryer Available Yes
    Gross Combined Weight 42000 lbs
    Shower Type Standard
    Electrical Service 50 amp

    Similar Floorplans

  • Embark 39BH

    Embark 39BH Floorplan Image

    Jayco Embark Class A diesel motorhome 39BH highlights: Full and Half Bath Bunk ... more about Embark 39BH

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 7
    Slides 3
    Length 39 ft 11 in
    Ext Width 8 ft 5 in
    Ext Height 0 ft
    Int Height 7 ft
    Exterior Color Desert Dusk, Night Flight, Summer Solstice
    Hitch Weight 10000 lbs
    Gross Weight 32000 lbs
    Fresh Water Capacity 100 gals
    Grey Water Capacity 62 gals
    Black Water Capacity 41 gals
    Tire Size 22.5
    Furnace BTU 20000 btu
    Generator Onan 8000 Watt Diesel with Auto Start
    Fuel Type Diesel
    Engine Cummins ISB Turbocharged
    Chassis Spartan K1 Raised Rail
    Horsepower 360 hp
    Fuel Capacity 100 gals
    Wheelbase 261 in
    Number Of Bunks 2
    Available Beds King
    Torque 800 ft-lb
    Refrigerator Type Whirlpool Residential
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 30" x 40"
    Number of Awnings 1
    Axle Weight Front 14329 lbs
    Axle Weight Rear 22000 lbs
    LP Tank Capacity 16.5 lbs.
    Water Heater Capacity 10 gal.
    Water Heater Type Gas/Electric
    AC BTU 30000 btu
    TV Info LR 50" LED HDTV, BR 32" LED HDTV, Exterior 39" LED HDTV
    Awning Info 17' Electric with LED Lights
    Washer/Dryer Available Yes
    Gross Combined Weight 42000 lbs
    Shower Type Standard
    Electrical Service 50 amp

    Similar Floorplans

  • Embark 39T2

    Embark 39T2 Floorplan Image

    Take a Virtual Tour

    Jayco Embark Class A diesel motorhome 39T2 highlights: Full and Half Bath Sleeps ... more about Embark 39T2

    Specifications

    Sleeps 7
    Slides 3
    Length 39 ft 11 in
    Ext Width 8 ft 5 in
    Ext Height 12 ft 10 in
    Int Height 7 ft
    Exterior Color Desert Dusk, Night Flight, Summer Solstice
    Hitch Weight 10000 lbs
    Gross Weight 32000 lbs
    Dry Weight 28956 lbs
    Fresh Water Capacity 100 gals
    Grey Water Capacity 62 gals
    Black Water Capacity 41 gals
    Tire Size 22.5
    Furnace BTU 30000 btu
    Generator Onan 8000 Watt Diesel with Auto Start
    Fuel Type Diesel
    Engine Cummins ISB Turbocharged
    Chassis Spartan K1 Raised Rail
    Horsepower 360 hp
    Fuel Capacity 100 gals
    Available Beds King
    Torque 800 ft-lb
    Refrigerator Type Whirlpool Residential
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 30" x 40"
    Number of Awnings 1
    Axle Weight Front 14329 lbs
    Axle Weight Rear 22000 lbs
    LP Tank Capacity 16.5 lbs.
    Water Heater Capacity 10 gal.
    Water Heater Type Gas/Electric
    AC BTU 30000 btu
    Basement Storage 145 cu. ft.
    TV Info LR 50" LED HDTV, BR 32" LED HDTV, Exterior 39" LED HDTV
    Awning Info 17' Electric with LED Lights
    Washer/Dryer Available Yes
    Gross Combined Weight 42000 lbs
    Shower Type Standard
    Electrical Service 50 amp

    Similar Floorplans

Embark Features:

Standard Features (2019)



Customer Value Package

  • JRide Premium®
  • 8 KW Diesel Generator
  • 2,000 Watt Inverter
  • Two 15,000 BTU Air Conditioner with Heat Pump
  • Automatic Leveling Jacks
  • Backup and Sideview Cameras
  • Power Awning with LED Lights
  • Exterior Entertainment Center with LED TV
  • Solar Shades

Standard Driving Equipment

  • Automatic Hydraulic Leveling Jacks
  • Spartan® K1 Raised Rail Chassis
  • Cummins® ISB Turbocharged 360 HP Engine 800 LB-Foot Torque at 1,800 RPM
  • Allison® 3000 MH 6-Speed Transmission
  • 750 Watt Engine Block Heater
  • IFS Independent 12,000 LB Front Axle *S/B 12,600 LB Front Axle (37MB), 14,329 LB Front Axle (39BH, 39T2)
  • Rear Axle 20,000 LB *S/B 20,000 LB (37MB), 22,000 LB (39BH, 39T2)
  • 4.88 Rear Axle Ratio
  • 10,000 LB Hitch with 7/4-Pin Plug
  • Rear-Mounted Radiator
  • ABS Drum Brakes on Front and Rear
  • Variable Geometry Turbo (VGT) Brake
  • Bilstein® 46MM Shocks
  • 100 Gallon Fuel Tank, Driver Side Fill
  • 10 Gallon DEF Tank, Driver Side Fill
  • Michelin® 275/80R 22.5” Tires
  • Two 12V Chassis Batteries
  • 170 AMP Alternator
  • Remote Air Connection
  • Hydraulic Automatic Leveling

Standard Construction Equipment

  • X-Bridge Frames Welded into Chassis Frame
  • Enclosed, Insulated Storage Area
  • Insulation with Reflective Flexfoil® Roof (R-24), Front and Rear Caps (R-22)
  • Floor with Vacuum-Bonded Layers of Darco Underbelly, a Welded Aluminum Frame, R-9 Bead-Foam Insulation, and 5/8" Decking
  • High-Gloss Gelcoat, Vacuum-Bonded, Laminated with R-8 Bead-Foam Insulation Sidewalls
  • Electric-Powered Slideout Rooms
  • One-Piece Fiberglass Roof with 3/8" Plywood Decking and 4" Arched Aluminum Roof Truss
  • Steel-Reinforced Front Cap and Windshield Frame

Heat, A/C, Power, and Water Equipment

  • 16.5 Gallon Propane Tank
  • 10 Gallon Gas/Electric Water Heater
  • 35,000 BTU Furnace (37MB)/ 1-20,000 and 1-30,000 (39BH, 39T2)
  • Two 15,000 BTU Standard Profile A/C with Heat Pump
  • 50 AMP Power Cord
  • Onan® 8,000 Watt Diesel Generator with Auto Gen Start on Slideout Tray
  • 2,000 Watt Pure Sine Wave Inverter with 100 AMP Battery Charger
  • Two L16 AGM Batteries (6V/390 AMP Hours Each)
  • Surge Protector Transfer Switch
  • Black Holding Tank Sprayer
  • Macerator Holding Tank Dump System with Manual Gate Valves
  • City and Tank Water Filtration System
  • Winterizing Drain System

Standard Exterior Equipment

  • 3M Front Protective Film Mask
  • Halogen High and Low Beam Headlights
  • Halogen Fog Lights
  • Daytime Running Lights
  • LED Marker, Turn Lights, Docking Lights, and Accent Lights
  • Keyless Entry
  • Power Patio Awning with LED Lights
  • Power Entrance Door Awning with LED Lights
  • Slideout Awnings
  • Heated, Remote Controlled, Sideview Mirrors with Integrated Cameras
  • Frameless, Dual-Pane, Tinted, Safety-Glass Windows
  • Exterior 39" Insignia LED HDTV
  • Exterior Utility Center with System Monitor Panel
  • Winegard® In-Motion Satellite Dome with Area Prepped for Trav'ler Satellite Dish
  • Winegard Rayzar Z1 TV Antenna
  • Full-Width Rear Mudflap with Chrome Name Plate

Standard Cockpit Amenities

  • Powered Front Sun Visors and Privacy Shade
  • Power Adjustable Driver and Passenger Seats with 3-Point Belt
  • Tilt and Telescoping Steering Wheel with Integrated Controls for Cruise and Wipers
  • Spartan Message Center with LCD Display Featuring: Odometer, Tachometer, Fuel Economy, Fuel Remaining, Outside Air Temperature, Coolant Temperature, Engine Oil Temperature and Pressure, Transmission Temperature, Turbo Boost Pressure, Air Pressure, Trip Meter, Speed, and Voltage
  • Sony 6.4" Receiver with Sirius
  • Two 6.5" Speakers
  • Floor-Mounted Foot Pedals
  • Color Side and Rearview Cameras
  • Dual USB Ports

Standard Interior Equipment

  • Touchpad System for Integration of Coach Controls
  • LED Recessed 12V Lighting
  • Polished Tile Flooring
  • Manual Solar Day and Black Out Night Shades
  • Insignia™ 50" LED HDTV in Living Area
  • Insignia Sound Bar in Living Room
  • Blu-Ray™ Player in Living Area and Bedroom

Standard Kitchen Equipment

  • Solid-Surface Countertops with Stainless Steel Sink
  • Large, Deep Drawer with Waste Basket
  • Induction Cooktop
  • Frigidaire® 1.5 Cubic Foot Convection Microwave Oven
  • Whirlpool® Residential Refrigerator with Ice Maker and Water Dispenser
  • Power Vent

Standard Bedroom Equipment

  • King-Size, Thick-Foam Mattress (37MB)
  • King-Size, Power Head-Lift Mattress (39BH, 39T2)
  • Insignia 32" LED HDTV
  • Blue-Ray Player in Living Area

Standard Bathroom Equipment

  • Solid-Surface Countertop with Integrated Sink
  • Thetford® Aqua Magic Style 2 Toilet with Foot Flush
  • One-Piece Fiberglass Shower with Skylight
  • Power Vent

Standard Safety Equipment

  • Three Security Lights
  • Smoke Alarm
  • Carbon Monoxide Detector
  • Propane Alarm

Exterior

  • Desert Dusk Paint
  • Night Flight Paint
  • Summer Solstice

Options

  • Canadian Standards
  • Customer Value Package
    • JRide Premium
    • 8 KW Diesel Generator
    • 2,000 Watt Inverter
    • Two 15,000 BTU Air Conditioner with Heat Pump
    • Automatic Leveling Jacks
    • Backup and Sideview Cameras
    • Power Awning with LED Lights
    • Exterior Entertainment Center with LED TV
    • Solar Shades
  • Fireplace 1,500 Watt LED (37MB Only)
  • Central Vacuum System
  • Theater Seating with Power Recline
  • Winegard Trav'ler Satellite Dish
  • Canadian Shaw Trav'ler Satellite Dish - Direct TV
  • Wi-Fi Extender Antenna (4G LTE)
  • Slideout Storage Tray
  • Prep for Solar Power
  • Washer/Dryer Stacked



See us for a complete list of features and available options!

All features and specifications are subject to change.
